OptiX Keynotes
Every form of optical interface to date has stood the test of time – madi, midi (optically coupled), ADAT, s/pdif.
This is because the optical interface galvanically isolates each end from any possible interference, including thunderstorms, which makes it fundamentally reliable. People like that kind of reliability.
The BrikWorm OptiX (Optical-to-XLR) takes advantage of this built-in robustness, using 2 light pipes per unit, one to send data and one to receive. Each light pipe carries audio, control and synchronisation information as required.
As well has having some great remote-controllable features, there is one thing about the OptiX modules which makes them incredibly flexible - each 1u module is only 5cm deep (even the 80W power supply), making it possible to wall-mount in stud walling, assemble in a briefcase, etc, limited only by your imagination.
Trad, Live and ProLive modules may be mixed and matched as you require.
OptiX In
Pro-Live
Features
- analogue gain
- phantom power
- -20dB input pad
- phase invert
- switchable high-pass filter: 80Hz, 18dB per octave
- status LED for pad/phantom/phase/high-pass filter
- LED VU meter with PeakFade
- metal connectors
- local and remote midi control
- micro SD card
- BlinkOn: instant-on without needing to save data
- up to 96kHz
- word clock out
Live
Features
- analogue gain
- phantom power
- plastic connectors
- -20dB input pad
- phase invert
- status LED for pad/phantom/phase
- remote midi control
- BlinkOn: instant-on without needing to save data
- 44.1/48.0kHz
Trad
Features
- 12dB stepped gain
- phantom power
- plastic connectors
- remote midi control
- status LED for phantom power
- 44.1/48.0kHz
OptiX Out
Pro-Live
Features
- output attenuation 0.5dB steps
- phase invert
- phantom power detectors
- metal connectors
- local and remote midi control
- micro SD card
- LED VU meter with PeakFade
- BlinkOn
- 96 kHz
Live
Features
- output attenuation 0.5dB steps
- phase invert
- plastic connectors
- remote midi control
- BlinkOn
Trad
Features
- plastic connectors
TosCAT
TosLink (POF Plastic Optical Fibre) to CAT5 converter: used to extend the range of the optical cables, using all four pairs of the CAT5 as transmission lines.
The TosCAT has 8/16/24 optical interfaces to allow a total of 32/64/96 audio channels, including DMX, to travel down a single CAT5.
An additional auxiliary optical port is provided on the Live and Pro-Live versions for additional features, like the DMX.
Example formats illustrated below - for the full listing see the Features Matrix.
96-channel - Pro-Live version
Features
- metal connectors
- local and remote and variable midi control
- micro SD card
- BlinkOn: instant-on without needing to save data
- auxiliary optical port (for DMX)
- redundant cable
64-channel - Live version
Features
- plastic connectors
- local and remote and variable midi control
- micro SD card
- BlinkOn: instant-on without needing to save data
- auxiliary optical port (for DMX)
32-channel - Trad version
Features
- plastic connectors
- local midi control
- micro SD card
Power Magic
The BrikWorm system is powered down the cable, therefore the power supply Brik can be located anywhere in the daisy chain.
If you inject power through the RJ11s on the rear of the TosCAT, it comes out of the Ethercons on the front; if you inject through the Ethercons, it comes out via the RJ11s.
Control
MIDI
That's it!
The rest of this page is intentionally blank.
Features Matrix
Trad |
Live |
ProLive |
|
Inputs Stage | |||
12dB Stepped gain | x |
||
Plastic connectors | x |
x |
|
44.1/48.0kHz | x |
x |
x |
Phantom power | x |
x |
x |
Status LED for phantom power | x |
x |
x |
Remote midi control | x |
x |
x |
Analogue gain | x |
x |
|
BlinkOn (instant-on) | x |
x |
|
-20dB Input pad | x |
x |
|
Phase invert | x |
x |
|
Status LED for pad/phase invert | x |
x |
|
Switchable high-pass filter | x |
||
96kHz | x |
||
Status LED for high-pass filter | x |
||
LED VU meter with PeakFade | x |
||
Local midi control | x |
||
Metal connectors | x |
||
Micro SD card | x |
||
Word clock out | x |
||
Inputs Mixer | Trad |
Live |
ProLive |
Plastic connectors | x |
x |
|
44.1/48.0kHz | x |
x |
x |
BlinkOn | x |
x |
|
Phase invert | x |
x |
|
96kHz | x |
||
LED VU meter with PeakFade | x |
||
Local midi control | x |
||
Metal connectors | x |
||
Micro SD card | x |
||
Word clock out | x |
||
Outputs Stage | Trad |
Live |
ProLive |
Plastic connectors | x |
x |
|
44.1/48.0kHz | x |
x |
x |
BlinkOn | x |
x |
|
Output attenuation 0.5dB steps | x |
x |
|
Phase invert | x |
x |
|
96 kHz | x |
||
LED VU meter with PeakFade | x |
||
Metal connectors | x |
||
Micro SD card | x |
||
Outputs Mixer | Trad |
Live |
ProLive |
Plastic connectors | x |
x |
|
44.1/48.0kHz | x |
x |
x |
BlinkOn | x |
x |
|
Output attenuation 0.5dB steps | x |
x |
|
Phantom power detectors | x |
x |
|
Phase invert | x |
x |
|
96 kHz | x |
||
LED VU meter with PeakFade | x |
||
Metal connectors | x |
||
Micro SD card | x |
||
Power Supply | Trad |
Live |
ProLive |
80W | x |
x |
x |
Power meter | x |
x |
|
Ethercons | option |
option |
option |
TosCAT (32/64/96) | Trad |
Live |
ProLive |
Plastic connectors | x |
x |
|
Local midi control | x |
x |
x |
Micro SD card | x |
x |
x |
BlinkOn | x |
x |
|
Variable midi control | x |
x |
|
Auxiliary port | x |
x |
|
Metal connectors | x |
||
Redundant cable | x |
